DC-A22 Conductor Assignments
Figure 28. DC-A22 Conductor Assignments
Trigno
Output
Trigno
Pin
Conductor Color
Primary / Secondary
Trigno
Output
Trigno
Pin
Conductor Color
Primary / Secondary
EMG 1 68 Violet / Orange AY 9 16 Tan / Violet
AX 1 67 Blue / Orange AZ 9 17 Tan / Gray
AY 1 33 Orange / Blue EMG 10 49 Blue / Tan
AZ 1 34 Orange / Violet AX 10 48 Green / Tan
EMG 2 66 Green / Orange AY 10 14 Tan / Green
AX 2 65 Yellow / Orange AZ 10 15 Tan / Blue
AY 2 31 Orange / Yellow EMG 11 47 Yellow / Tan
AZ 2 32 Orange / Green AX 11 46 Orange / Tan
EMG 3 64 Gray / Pink AY 11 12 Tan / Orange
AX 3 63 Violet / Pink AZ 11 13 Tan / Yellow
AY 3 29 Pink / Violet EMG 12 45 Pink / Tan
AZ 3 30 Pink / Gray AX 12 44 Brown / Tan
EMG 4 62 Blue / Pink AY 12 10 Tan / Brown
AX 4 61 Green / Pink AZ 12 11 Tan / Pink
AY 4 27 Pink / Green EMG 13 42 Violet / White
AZ 4 28 Pink / Blue AX 13 41 Blue / White
EMG 5 60 Yellow / Pink AY 13 7 White / Blue
AX 5 59 Orange / Pink AZ 13 8 White / Violet
AY 5 25 Pink / Orange EMG 14 40 Green / White
AZ 5 26 Pink / Yellow AX 14 39 Yellow / White
EMG 6 58 Gray / Brown AY 14 5 White / Yellow
AX 6 57 Violet / Brown AZ 14 6 White / Green
AY 6 23 Brown / Violet EMG 15 38 Orange / White
AZ 6 24 Brown / Gray AX 15 37 Pink / White
EMG 7 55 Green / Brown AY 15 3 White / Pink
AX 7 54 Yellow / Brown AZ 15 4 White / Orange
AY 7 20 Brown / Yellow EMG 16 36 Brown / White
AZ 7 21 Brown / Green AX 16 35 Tan / White
EMG 8 53 Orange / Brown AY 16 1 White / Tan
AX 8 52 Pink / Brown AZ 16 2 White / Brown
AY 8 18 Brown / Pink
GND 9 White / Gray
AZ 8 19 Brown / Orange
GND 22 Brown / Blue
EMG 9 51 Gray / Tan
GND 43 Gray / White
AX 9 50 Violet / Tan
NC 56 Blue / Brown
