DELTA DORE Tybox 1137 - Installing the Transmitter; Location; Mounting

3
PROG x 1
PROG x 7
~1,50 m
> 20 cm
1. Installing the transmitter
1.1 Location
The thermostat can be wall-mounted or placed
on a piece of furniture in a room where the
temperature is to be regulated from, at a
recommended height of 1.5m and away from any
heat sources (replace, direct sunlight, etc.) or
draughts (window, door, etc.).
IMPORTANT: Do not install the thermostat on
a wall in contact with the outside or with an
unheated room (e.g. garage, etc.).
1.2 Mounting
❶ Separate the box from its base.
❷ Insert the baeries
WARNING: make sure you insert the baeries
facing the right way and that they are the right
type (no lithium baeries).
❸ Toggle the switch to choose the programme
type: weekly (A) or daily (B).
❹ Secure the transmier with suitable screws
to the wall-mount or use the supplied stand to
place it on a at (non-metallic) surface.
❺❻ Close and lock the box.
INSTALLATION
Wall mounting Fied on base
