Chapter 1 Unpacking Check and Model Explanation|ASDA-A&A+ Series
Revision April 2009 1-7
1.3 Servo Drive and Servo Motor Combinations
The table below shows the possible combination of Delta ASDA-A and ASDA-A+ series servo drives and
ASMT and ECMA series servo motors. The boxes () in the model names are for optional configurations.
(Please refer to Section 1.2 for model explanation)
ASDA-A Series Servo Drive
Servo drive Servo motor
100W ASD-A0121L ASMT01L250
200W ASD-A0221L ASMT02L250
400W ASD-A0421L
ASMT04L250
750W ASD-A0721L ASMT07L250
1000W ASD-A1021L
ASMT10L250
2000W ASD-A2023L ASMT20L250
Low
inertia
3000W ASD-A3023L
ASMT30L250
1000W ASD-A1021M ASMT10M250
1500W ASD-A1521M
ASMT15M250
2000W ASD-A2023M ASMT20M250
Medium
inertia
3000W ASD-A3023M
ASMT30M250
