Delta Electronics VFD-M Series User Manual

Chapter 3 Keypad and Start Up|
3-2 Revision May 2008, ME14, SW V3.04
Displayed Message Descriptions
The actual value stored within the specified parameter.
The AC drive forward run status.
The AC drive reverse run status.
“End” displays for approximately 1 second if input has been
accepted. After a parameter value has been set, the new value is
automatically stored in memory. To modify an entry, use the
and
keys.
“Err” displays, if the input is invalid.
3.1.2 How to Operate the Digital Keypad LC-M02E
MODE
ENTER
or
START
MODE MODE MODE MODE
GO START
ENTER
ENTER
MODE
START
To set direction
or or
(When operatio n so ur ce is d igital keypad)
To modify data
NOTE: In the paramete r setting mode, you can press to return to the selection mode.
MODE
parame ter set
successfully
or
para me te r set
er ror
move to previous
display
NOTE: In the selection mode, press to set the paramet ers.
ENTER
Selection mode
To se t pa r a met e r s

Delta Electronics VFD-M Series Specifications

General

Enclosure Rating	IP20
Output Voltage	Matches input voltage
Overload Capacity	150% for 60 seconds
Control Mode	V/F control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Analog Inputs	2
Communication Interface	RS-485 (Modbus RTU)
Storage Temperature	-20°C
Humidity	90% RH, non-condensing
Cooling Method	Fan cooled
