Chapter 3 Keypad and Start Up|
Revision May 2008, ME14, SW V3.04 3-3
3.1.3 LC-M02E
Unit: mm [inch]
Reference Table for the 7-segment LED Display of the Digital Keypad
Digit 0 1 2 3 4 5 6 7 8 9
LED
Display
English
alphabet
A b Cc d E F G Hh I Jj
LED
Display
English
alphabet
K L n Oo P q r S Tt U
LED
Display
English
alphabet
v Y Z
LED
Display
