Appendix B Accessories|
B-6 Revision May 2008, ME14, SW V3.04
B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model Input Current (A) Output Current (A)
I (A) Bussmann P/N
VFD002M11A 6 1.6 15 JJN-15
VFD004M11A 9 2.5 20 JJN-20
VFD007M11A 16 4.2 30 JJN-30
VFD004M21A 6.3 2.5 15 JJN-15
VFD004M21B 6.3 2.5 15 JJN-15
VFD007M21A 11.5 5.0 20 JJN-20
VFD007M21B 11.5 5.0 20 JJN-20
VFD015M21A 15.7 7.0 30 JJN-30
VFD015M21B 15.7 7.0 30 JJN-30
VFD022M21A 27 10 50 JJN-50
VFD004M23A 2.9 2.5 5 JJN-6
VFD007M23A 7.6 5.0 15 JJN-15
VFD015M23A 8.8 7.0 20 JJN-20
VFD022M23B 12.5 10.0 30 JJN-30
VFD037M23A 19.6 17 40 JJN-40
VFD055M23A 28 25 50 JJN-50
VFD007M43B 4.2 3.0 5 JJS-6
VFD015M43B 5.7 4.0 10 JJS-10
VFD022M43B 6.0 5.0 15 JJS-15
VFD037M43A 8.5 8.2 20 JJS-20
VFD055M43A 14 13 30 JJS-30
VFD075M43A 23 18 50 JJS-50
VFD007M53A 2.4 1.7 5 JJS-6
VFD015M53A 4.2 3.0 10 JJS-10
VFD022M53A 5.9 4.2 15 JJS-15
VFD037M53A 7.0 6.6 15 JJS-15
VFD055M53A 10.5 9.9 20 JJS-20
VFD075M53A 12.9 12.2 30 JJS-50
