Chapter 4 Parameters|
4-2 Revision May 2008, ME14, SW V3.04
4.1 Summary of Parameter Settings
: The parameter can be set during operation.
Parameter Explanation Settings
Factory
Setting
Customer
Pr.00 Source of Frequency
Command
00: Master frequency determined by digital
keypad (LC-M02E)
01: Master frequency determined by 0 to
+10 V input on AVI terminal with jumpers
02: Master frequency determined by 4 to
20mA input on ACI terminal with jumpers
03: Master frequency determined by RS-485
Communication port
04: Master frequency determined by
potentiometer on digital keypad
00
Pr.01 Source of Operation
command
00: Operation determined by digital keypad
01: Operation determined by external control
terminals, keypad STOP is effective
02: Operation determined by external control
terminals, keypad STOP is ineffective
03: Operation determined by RS-485
communication port, keypad STOP is
effective
04: Operation determined by RS-485
communication port, keypad STOP is
ineffective
00
Pr.02 Stop Method 00: Ramp stop
01: Coast Stop
00
Pr.03 Maximum Output
Frequency
50.00 to 400.0 Hz 60.00
Pr.04 Maximum Voltage
Frequency (Base
Frequency)
10.00 to 400.0Hz 60.00
115V/230V: 0.1 to 255.0V 220.0
460V: 0.1 to 510.0V 440.0
Pr.05
Maximum Output
Voltage (Vmax)
575V: 0.1 to 637.0V 575.0
Pr.06 Mid-point Frequency 0.10 to 400.0Hz 1.50
115V/230V: 0.1 to 255.0V 10.0
460V: 0.1 to 510.0V 20.0
Pr.07 Mid-point Voltage
575V: 0.1 to 637.0V 26.1
