Chapter 4 Parameters|
Revision May 2008, ME14, SW V3.04 4-5
Parameter Explanation Settings
Factory
Setting
Customer
13: Base-block (B.B.) (N.C)
14: Increase Master Frequency
15: Decrease Master Frequency
16: Run PLC Program
17: Pause PLC
18: Counter Trigger Signal
19: Counter Reset
20: No function
21: RESET command (N.C)
22: Control source: External Terminal
23: Control source: Keypad
24: Control source: Communication
25: Parameter Lock (Write disable, Read is
always 0)
26: PID Disable (N.O.)
27: PID Disable (N.C.)
28: Second Source for Frequency Command
29: Forward (contact is open) / Reverse
(contact is close)
30: One-Shot PLC Run
31: Index input signal
32: Counter Incremented by Drive Output
Frequency
Pr.43 Analog Output Signal
00: Analog Frequency Meter (0 to Maximum
Output Frequency)
01: Analog Current Meter (0 to 250% of the
rated AC drive current)
02: Feedback signal (0 - 100%)
03: Output power (0 - 100%)
00
Pr.44 Analog Output Gain 00 to 200 % 100
Pr.45
Multi-Function Output
Terminal 1
(Photocoupler output)
00
Pr.46
Multi-function Output
Terminal 2
(Relay Output)
00: AC Drive Operational
01: Maximum Output Frequency Attained
02: Zero Speed
03: Over-Torque Detection
04: Base-Block (B.B) Indication
05: Low Voltage Indication
06: AC Drive Operation Mode
07: Fault Indication
08: Desired Frequency Attained
07
To Next Page
