3U Turbo CPU Board for UMAC Turbo and Turbo Stack
Turbo CPU Board Jumpers and Pinouts 13
BOARD JUMPERS AND PINOUTS
The Location columns of the following tables refer to the mapped locations shown in the drawing below:
CPU Card Layout
Note:
Pin 1 of an E-point is masked by an X in white ink on the composite side, and by a
square solder pad on the solder side.
E0: Factory Use Only
