3U Turbo CPU Board for UMAC Turbo and Turbo Stack
Turbo PMAC2 3U CPU Board Connector Summary 17
BOARD CONNECTOR SUMMARY
J1:
Stack Connector
J2:
Stack Connector
J1A, B:
PC/104 Main Connector, 64-pin prong connector (Option 2 required)
J2C, D:
PC/104 AT Connector, 40-pin prong connector (Option 2 required)
J5:
JTAG/OnCE (for factory use only): 10-pin IDC connector
J6:
JISP (for factory use only): 8-pin SIP connector
J7: *
RS-232/RS-422 Serial Port Connector
J8: *
Auxiliary RS-232 Serial Port (Option 9T required)
J21:
JISP_B (for factory use only) (SIP 8 connector)
P1:
UBUS Expansion Port (96-pin DIN connector)
TB1: *
JPWR Power Supply Connector: 4-point terminal block
* Pinouts shown in next section. Connectors not flagged with an asterisk are for internal use or factory
setup.
