9
UNPACKING AND CLEANING
Carefully unpack the machine and all loose items from
the shipping container(s). Remove the protective coating
from all unpainted surfaces. This coating may be removed
with a soft cloth moistened with kerosene (do not use
acetone, gasoline or lacquer thinner for this purpose). After
cleaning, cover the unpainted surfaces with a good quality
household floor paste wax.
The basic saw unit is shown as shipped here in Fig. 2.
ASSEMBLY
ASSEMBLY TOOLS REQUIRED
* Phillips head screw driver (not supplied)
* 12mm, 13mm and 18mm open end wrenches (not supplied)
* Other wrenches and a drill with a 1/4 inch bit may be required, depending on what fence or tables will be used
ASSEMBLY TIME ESTIMATE - 2 to 3 hours
Fig. 2
FOR YOUR OWN SAFETY, DO NOT CONNECT THE MACHINE TO THE POWER SOURCE UNTIL
THE MACHINE IS COMPLETELY ASSEMBLED AND YOU READ AND UNDERSTAND THE ENTIRE
INSTRUCTION MANUAL.
THE SAW IS EXTREMELY HEAVY. HAVE TWO OR MORE PEOPLE HELP LIFT AND MOVE
MACHINE AROUND DURING ASSEMBLY.
