14
OPERATION
STARTING AND STOPPING JOINTER
To turn the machine “ON”, push the green start button
(A) Fig. 17. To turn the machine “OFF”, push the red
stop button (B).
LOCKING SWITCH IN THE “OFF”
POSITION
IMPORTANT: When the tool is not in use, the switch
should be locked in the “OFF” position to prevent
unauthorized use, using a padlock (C) Fig. 18 with a
3/16" diameter shackle.
Fig. 17
Fig. 18
A
B
C
OPERATIONAL CONTROLS AND ADJUSTMENTS
