CARTON CONTENTS
Fig. 2
1. Jointer
2. Rabbeting Ledge
3. Motor Pulley
4. Fence
5. Cutterhead Guard
6. Fence Carriage Assembly
1
2
3
4
5
6
7
8
9
10
11
12
7. Fence Tilting Handle
8. 10x13mm Open End Wrench
9. 4mm Hex Wrench
10. 2.5mm Hex Wrench
11. M8x1.25x25mm Socket Head Screw (8)
12. M8.1 Lockwasher (8)
Carefully unpack the machine and all loose items from the shipping container(s). Remove the protective coating from
all unpainted surfaces. This coating may be removed with a soft cloth moistened with kerosene (do not use acetone,
gasoline or lacquer thinner for this purpose). After cleaning, cover the unpainted surfaces with a good quality household
floor paste wax.
NOTICE: THE MANUAL COVER PHOTO ILLUSTRATES THE CURRENT PRODUCTION MODEL. ALL OTHER
ILLUSTRATIONS ARE REPRESENTATIVE ONLY AND MAY NOT DEPICT THE ACTUAL COLOR, LABELING OR
ACCESSORIES AND MAY BE INTENDED TO ILLUSTRATE TECHNIQUE ONLY.
UNPACKING AND CLEANING
