Delta 43-431 - CARTON CONTENTS; List of Included Components

7
1. 10" Wide Cast Iron Extension Wings (2)
2. Wrenches (2)
3. 7/16-20 x 1" Hex Cap Screws (6) for mounting
extension wings
4. 7/16"Flat Washers (6) for mounting extension wings
5. Handwheel
6. Key for Handwheel
7. Lock Knob
8. Safe Guard II Spindle Guard
9. 3/4" I.D. Washer (2)
10. 3/4" I.D. x 1/2" Thick Collar
11. 3/4" I.D. x 3/4" Thick Collar
12. 3/4" I.D. x 1" Thick Collar
13. Spindle Nut
14. Keyed Washer
15. Spindle
16. Tie Rod
17. Tie Rod Nut
18. Keps Nut (2) for mounting switch to switch-
mounting bracket
19. 10-32 x 1/2"Phillips Head Screw (2) for mounting
switch to switch-mounting bracket
20. 1/4-20 Flange Nut (4) for mounting switch
mounting bracket to shaper
21. 1/4-20 x 7/8" Truss Head Machine Screw (4) for
mounting switch mounting bracket to shaper
22. Switch Adapter Plate (2) for mounting switch
mounting bracket to shaper
23. Starting Pin
Fig. 1
1
2
3
4
13
10
11
12
14
15
16
17
9
8
7
6
5
18
19
20
21
23
22
CARTON CONTENTS
