SAW FEATURES
The part names and part numbers correspond to those used in the Assembly. Operations and Maintenance sections of this manual.
The use of any accessory or attachment or performance of any operation with this tool other than those
recommended in this instruction manual may present a risk personal injury.
1. Water Tray
2. Front rail, main frame
3. Miter guide
4. Worktable
5. Motor/arm assembly
6. Water hose
7. Submersible pump (not pictured)
8. Diamond blade
9. Blade guard
10. Plunge lock knob
11. Blade stop adjustment knob
12. Bevel lock knob
13. Splash guard
14. On/Oswitch(notpictured)
15. Drain plug (not pictured)
16. Upper Splash Tray
17. Table Extension
18. Side Splash Tray
16
13
12
5
10
6
3
2
4
1
9
11
8
17
18
