Delta AC MAX User Manual

v1.0.0
17
Single phase Three phase
IT IT
(Optional) active power control
Users can control the EVSE with external components (e.g. a ripple control receiver from the power supplier,
a domestic controller, a time switch, a combination lock, a photovoltaic system, etc.).
Note: Ensure that hazardous voltages are isolated safely.
1. Based on the tenon, attach the connector to the inner
surface of EVSE along the edge.
2. Connect the control board
3. Remove the water proof cap and pass through the signal
cable with appropriate conduit or cable gland.
