AS Series Module Manual
4- 14
4.2.7 LED Indicators
Number Name Description
1 RUN LED Indicator
Operating status of the module
ON: the module is running.
OFF: the module is not running.
2 ERROR LED Indicator
Error status of the module
ON: a serious error exists in the module.
OFF: the module is operating normally.
Blink: a minor error exists in the module.
3
Digital to Analog
Conversion Indicator
Digital-to-analog conversion status
Blinking: conversion is in process.
OFF: conversion has stopped.
4.3 HWCONFIG in ISPSoft
4.3.1 Initial Setting
(1) Start ISPSoft and double-click HWCONFIG.
