9. Recording channels
Record the input values of the cyclic sampling for each channel. The system saves up to 500 data points and
the recording time is 10 ms.
Instruction for recording Recordin g e nds
500 records o f d ata
Time
Valu e of the chan nel
8.2.6 Wiring
 External wiring
(Impedance: Less than 100 )
CH1
SIG+
SIG-
SEN+
SEN-
*1
Connected to
on a power supply module
System
ground
Third ground
EXC+
EXC-
SIG+
SIG-
SEN+
SEN-
EXC+
EXC-
A+5V
AGND
A+5V
AGND
0V
24V
DC/DC
converter
A+5V
AGND
Four-wire
Six-wire
CH2
