Chapter 11 DeviceNet Master Scanner Module AS01DNET-A
11-45
1
11.4.10.3. Baud Rate Setting of When AS01DNET-A is in Slave Mode
1. Opening the DeviceNet Builder software, the following window appears.
2. Selecting Setup>> Communication Setting, the following dialog box appears. Select the driver for connection of
AS PLC and PC as below. Click OK to finish the selection of Driver.
