6.2.5 AS06RTD Control Registers
*If you use HWCONFIG to set values in CRs, once the set value is downloaded, the values can be retained in
the module; however if you use TO instruction to write data into CRs, the values CANNOT be retained, after
power failure or after transition of the CPU from STOP to RUN.
Note: The attribute of the CR must be W (write) to use TO instruction.
CR# Name Description Atr. Defaults
0
Format Setup
0: integer format
1: floating point format
R
0
1
Channel 1 mode setup
0: closed
1：0–300 Ω (default)
2：0–3000 Ω
3：Pt100
4：JPt100
5：Pt1000
6：Ni100
7：Ni1000
8：LG-Ni1000
9：Cu50
10：Cu100
R/W
1
2
Channel 2 mode setup
3
Channel 3 mode setup
4
Channel 4 mode setup
5
Channel 5 mode setup
6
Channel 6 mode setup
7
Channel 1 offset
Range: -32768 to +32767
R/W
0
8
Channel 2 offset
9
Channel 3 offset
10
Channel 4 offset
11
Channel 5 offset
12
Channel 6 offset
13
Channel 1 gain
Range: -32768 to +32767
R/W
1000
14
Channel 2 gain
15
Channel 3 gain
16
Channel 4 gain
17
Channel 5gain
18
Channel 6 gain
19
Channel 1 average times
Range: 1–100
R/W
10
20
Channel 2 average times
