Chapter 9 Serial Communication Module AS00SCM
9- 3
9_
9.2 Specification, Function and Wiring
9.2.1 The functional specifications
 RS-485/RS-422 communication interface
Item
Specifications
Connector type
5- pin European-style terminal block, spring-clip connector
Transmission speed
300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 76800 115200 and
230400 bps
Communication
format
Stop bit: 1 bit and 2 bits
Parity bit: none, an odd parity bit, and an even parity bit
Data bit: 7 bits and 8 bits
Communication
protocol
Modbus ASCII/RTU
UD Link
 CANopen communication interface
Item
Specifications
Connector type
RJ45*2
Transmission speed
10k, 20k, 50k, 125k, 250k, 500k, and 1000k bps
Communication
protocol
AS remote mode (RTU mode)
CANopen (firmware V2.00 or later)
 Ethernet communication interface
Item
Specifications
Connector type
RJ45*2
Transmission speed
10M, 100Mbps
Communication
protocol
EtherNet/IP (firmware V2.02 or later), PROFINET (firmware V2.06 or later)
 Electrical specifications
Item
Specifications
Supply voltage
24 VDC
Electric energy
consumption
0.6 W
Weight
Approximately 169 g
