Delta ASD-M-0721 Series User Manual

Chapter 7 Motion Control ASDA-M
7-6 Revision December, 2014
Code Name of Variables
／Attribute
Descriptions
parameter ＃1 B
P0-35
020
(14h)
Mapping
parameter ＃2 B
Return the value of parameter P0-26 which is mapped by
P0-36
021
(15h)
Mapping
parameter ＃3 B
Return the value of parameter P0-27 which is mapped by
P0-37
022
(16h)
Mapping
parameter ＃4 B
Return the value of parameter P0-28 which is mapped by
P0-38
023
(17h)
Mapping monitor
variable ＃1 B
Return the value of parameter P0-09 which is the monitor
variables mapped by P0-17
024
(18h)
Mapping monitor
variable ＃2 B
Return the value of parameter P0-20 which is the monitor
variables mapped by P0-18
025
(19h)
Mapping monitor
variable＃3 B
Return the value of parameter P0-11 which is the monitor
variables mapped by P0-19
026
(1Ah)
Mapping monitor
variable ＃4 B
Return the value of parameter P0-12 which is the monitor
variables mapped by P0-20
039
(27h)
DI status
(processed) Hex
The processed DI status of the servo drive. Each bit
corresponds to one DI channel.
The source includes hardware channel / software P4-07
which is determined by P3-06.
040
(28h)
DO status
(hardware) Hex
The real status of Digital Output hardware. Each bit
corresponds to one DI channel.
041
(29h)
Drive status
Return the value of P0-46. Please refer to the description
of the parameter.
043
(2Bh)
CAP, data
capturing
The Data captured by CAP hardware from the latest time
Note: CAP could continuously capture many points.
048
(30h)
Auxiliary encoder
CNT
The value of pulse counter from auxiliary encoder (CN5)
049
(31h)
Pulse command
CNT
The value of pulse counter from pulse command (CN1)
050
(32h)
Speed command
(processed)
D1 Dec
The processed speed command. The unit is 0.1 r/min.
The source might be analog, register or position loop.
051
(33h)
Speed feedback
(immediate)
D1 Dec
Current actual speed of the motor. The unit is 0.1 r/min.
052
(34h)
Speed feedback
(filter)
D1 Dec
Current actual speed of the motor. The unit is 0.1 r/min
(has been through the low-pass filter).
053 Torque command
The processed torque command. The unit is 0.1 Percent
