Delta ASD-M-0721 Series User Manual

ASDA-M Chapter 2 Installation
Revision December, 2014 2-5
2.5 Specification of Circuit Breaker and Fuse
Caution: Please use the fuse and circuit breaker that is recognized by UL/CSA.
Servo Drive Model Circuit breaker Fuse (Class T)
Operation Mode General General
ASD-M-0721-
30A 50A
ASD-M-1521-
70A 140A
NOTE
If the servo drive equips with earth leakage circuit breaker for avoiding
electric leakage, please choose the current sensitivity which is over
200mA and can continue up to 0.1 seconds.
2.6 EMI Filters Selection
Item Power Servo Drive Model EMI Filter Model FootPrint
1 750W ASD-M-0721- 20TDT1W4D N
2 1500W ASD-M-1521- 20TDT1W4D N
EMI Filter Installation
All electronic equipment (including servo drive) generates high or low frequency noise
during operation and interfere the peripheral equipments via conduction or radiation. With
EMI Filter and the correct installation, much interference can be eliminated.
When installing servo drive and EMI Filter, please follow the instructions of the user manual
and make sure it meets the following specification.
1. EN61000-6-4 (2001)
2. EN61800-3 (2004) PDS of category C2
3. EN55011+A2 (2007) Class A Group 1
