Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 8 Optional Cards  MS300 (IP66 / NEMA 4X)
8-13
Electrical Specification
Power supply voltage
5
V
DC
(supplied by AC motor drive)
Insulation voltage
500
V
DC
Communication wire
power consumption
0.85 W
Power consumption 1 W
Weight
23 g
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
Operation / Storage
Operation: -10–50 ºC (temperature), 90% (humidity)
Storage: -25–70 ºC (temperature), 95% (humidity)
Shock / Vibration resistance
International standards:
IEC 61800-5-1, IEC 60068-2-6 / IEC 61800-5-1, IEC 60068-2-27
DeviceNet Connector
PIN Signal Color Definition
5
4
3
2
1
1 V+ Red 24 V
DC
2 H White Signal+
3 S - Ground
4 L Blue Signal-
5 V- Black 0 V
 LED Indicator & Troubleshooting
There are three LED indicators on CMM-DN01. POWER LED displays the status of power supply. MS
LED and NS LED are dual-color LEDs, displaying the connection status and error messages of the
communication module.
POWER LED
LED status Indication Corrective Action
On Power supply in abnormal status
Check the power supply of the CMM-DN01.
Off Power supply in normal status No action is required.
