Chapter 9 Specification MS300 (IP66 / NEMA 4X)
9-6
9-3 Environment for Operation, Storage and Transportation
Do not place the drive in a critical environment, such as direct contact with chemical substance and solvent, and
exposure to direct sunlight.
Environment
Installation
Location
PCB design is compliant with IEC 60364-1 / IEC 60664-1 Pollution Degree 2.
The outer case meets IP66 standard for indoor use. If the drive is for outdoor
application, avoid direct sunlight.
Surrounding
Temperature
Operation
IP66 /
NEMA 4X /
UL Type 4X
-20–40 C
-20–50 C with derating
Storage
-40–85 C
Transportation
-20–70 C
Non-condensing, non-freezing
Relative
Humidity
Operation 0–100 %
Storage / Transportation
Max. 95 %
No condense water
Air Pressure
Operation 86–106 kPa
Storage / Transportation 70–106 kPa
Pollution Level
IEC 60721-3
Operation Class 3C2; Class 3S2
Storage Class 2C2; Class 2S2
Transportation Class 1C2; Class 1S2
Concentrate prohibited
Altitude < 1000 m (> 1000 m with derating)
Package
Drop
Storage
ISTA procedure
1A (according to weight) IEC 60068-2-31
Transportation
Vibration
Operating
1.0 mm, peak to peak value range from 2–13.2 Hz; 0.7–2.0 G range from
13.2–55 Hz; 2.0 G range from 55–512 Hz; complies with IEC 60068-2-6.
Non-operating
2.5 G peak
5 Hz–2 kHz
0.015" maximum displacement
Impact
Operating 15 G, 11 ms; complies with IEC / EN 60068-2-27.
Non-operating 30 G
