Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 9 Specification  MS300 (IP66 / NEMA 4X)
9-5
General Specifications
Control
Characteristics
Control Method V / F, VFPG*
1
, SVC, FOC sensorless
Applied Motor IM (Induction Motor), Simple PM control (IPM and SPM)
Max. Output
Frequency
0.00–599.00 Hz
Starting Torque*
2
150 % / 3 Hz
V / F, SVC control for IM, Heavy duty
200 % / 0.5 Hz
FOC control for IM, Heavy duty
100 % / (1/20 of motor rated frequency)
SVC control for PM, Heavy duty
Speed Control
Range
*
2
1 : 50
V / F, SVC control for IM, Heavy duty
1 : 100 FOC control for IM, Heavy duty
1 : 20 SVC control for PM, Heavy duty
Overload
Capability
Normal duty: 120 % 60 sec., 150 % 3 sec.
Heavy duty: 150 % 60 sec., 200 % 3 sec.
Frequency
Setting Signal
0–10 V / -10–10 V
4–20 mA / 0–10 V
1 channel pulse input (33 kHz), 1 channel pulse output (33 kHz).
Main Function
Multiple motor switches (maximum four independent motor parameter settings),
Fast start-up, Deceleration Energy Back (DEB) function, Wobble frequency
function, Fast deceleration function, Master and Auxiliary frequency source
selectable, Momentary power loss ride thru, Speed search, Over-torque
detection, Torque limit, 16-step speed (max.), Accel./decel. time switch, S-curve
accel./decel., three-wire sequence, JOG frequency, Upper/lower limits for
frequency reference, DC injection braking at start and stop, PID control, Built-in
PLC (2K steps), Positioning function
Application
Macro
Built-in application parameter groups (selected by industry) and user-defined
application parameter groups.
Protection
Characteristics
Motor Protection Over-current, Over-voltage, Over-temperature, Phase loss
Stall Prevention
Stall prevention during acceleration, deceleration and running (independent
settings)
Accessory
Communication
Cards
DeviceNet,
EtherCAT
, EtherNet/IP, PROFIBUS DP, Modbus TCP, CANopen
External DC
Power Supply
EMM-BPS01 (DC 24 V power supply card)
Certifications CE, RCM, REACH, RoHS, TUV, UL
*1 Pulse input (MI7 terminal) is used as speed feedback.
*2 Control accuracy may vary depending on the environment, application conditions or different motors. For details, contact our
company or your local distributor.

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General

Series	MS300
Category	DC Drives
IP Rating	IP66
NEMA Rating	NEMA 4X
Control Method	V/F, SVC
Communication Interface	RS-485
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Altitude	Up to 1000m
Vibration	1.0G
Input Voltage	Single/Three Phase 200-240V, Three Phase 380-480V
