Chapter 9 Specification MS300 (IP66 / NEMA 4X)
9-4
9-2 460V Series
460V, three-phase
Frame A B
Model VFD_ _ _ _ _ _ _ SAA
1A5MS43_ _
2A7MS43_ _ 4A2MS43_ _
5A5MS43MN 5A5MS43MF
9A0MS43_ _
MN MF MN MF MN MF MN MF
Applicable Motor Output (kW)
0.4 0.75 1.5 2.2 2.2 3.7
Applicable Motor Output (HP)
0.5 1 2 3 3 5
Output Rating
Heavy
Duty
Rated Output
Capacity (kVA)
1.1 2.1 3.2 4.2 4.2 6.9
Rated Output
Current (A)
1.5 2.7 4.2 5.5 5.5 9
Carrier Frequency
(kHz)
2–15 (Default: 4)
Normal
Duty
Rated Output
Capacity (kVA)
1.4 2.3 3.5 5.0 5.0 8.0
Rated Output
Current (A)
1.8 3 4.6 6.5 6.5 10.5
Carrier Frequency
(kHz)
2–15 (Default: 4)
Input Rating
Rated Input
Current (A)
Heavy Duty
2.1 3.7 5.8 6.1 6.1 9.9
Normal Duty 2.5 4.2 6.4 7.2 7.2 11.6
Rated Voltage / Frequency
Three-phase AC 380–480 V, 50/60 Hz
Operating Voltage Range
(V
AC
)
323–528 (-15–10%)
Frequency Range (Hz)
47–63
Weight (kg)
2.35 2.65 2.6 2.8 2.8 3.1 3.6 3.8 3.45 3.95
Cooling Method
Convective cooling Fan cooling
EMC Filter
Optional Built-in Optional Built-in Optional Built-in
Optional
Built-in Optional Built-in
IP Rating
IP66 / NEMA 4X
Frame C
Model VFD_ _ _ _ _ _ _ SAA
13AMS43_ _
17AMS43_ _
MN MF MN MF
Applicable Motor Output (kW)
5.5 7.5
Applicable Motor Output (HP)
7.5 10
Output Rating
Heavy
Duty
Rated Output Capacity (kVA)
9.9 13
Rated Output Current (A) 13 17
Carrier Frequency (kHz) 2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA)
12 15.6
Rated Output Current (A) 15.7 20.5
Carrier Frequency (kHz) 2–15 (Default: 4)
Input Rating
Rated Input
Current (A)
Heavy Duty
14.3 18.7
Normal Duty 17.3 22.6
Rated Voltage / Frequency
Three-phase AC 380–480 V, 50/60 Hz
Operating Voltage Range (V
AC
) 342–528 (-15–10%)
Frequency Range (Hz) 47–63
Weight (kg)
4.25 4.95 4.25 5.05
Cooling Method
Fan cooling
EMC Filter
Optional Built-in Optional Built-in
IP Rating
IP66 / NEMA 4X
NOTE
The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current. See the derating curve
diagram for Pr.06-55 for more information.
When the load is a shock or impact load, use a higher level model.
