Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 9 Specification  MS300 (IP66 / NEMA 4X)
9-3
230V, three-phase
Frame A B C
Model VFD_ _ _ _ _ _ _SAA 2A8MS23MN 4A8MS23MN 7A5MS23MN 11AMS23MN 17AMS23MN 25AMS23MN
Applicable Motor Output (kW)
0.4 0.75 1.5 2.2 3.7 5.5
Applicable Motor Output (HP)
0.5 1 2 3 5 7.5
Output Rating
Heavy
Duty
Rated Output Capacity
(kVA)
1.1 1.8 2.9 4.2 6.5 9.5
Rated Output Current (A) 2.8 4.8 7.5 11 17 25
Carrier Frequency (kHz) 2–15 (Default: 4)
Normal
Duty
Rated Output Capacity
(kVA)
1.2 1.9 3.0 4.8 7.4 10.3
Rated Output Current (A) 3.2 5 8 12.5 19.5 27
Carrier Frequency
(kHz)
2–15 (Default: 4)
Input Rating
Rated Input
Current (A)
Heavy Duty
3.4 5.8 9.0 13.2 20.4 30
Normal Duty 3.8 6.0 9.6 15 23.4 32.4
Rated Voltage / Frequency
Three-phase AC 200–240 V, 50/60 Hz
Operating Voltage Range (V
AC
)
170–264 (-15–10%)
Frequency Range (Hz)
47–63
Weight (kg)
2.3 2.45 2.75 3.4 3.5 4.25
Cooling Method
Convective cooling Fan cooling
EMC Filter
Optional
IP Rating
IP66 / NEMA 4X
NOTE
 The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current. See the derating curve
diagram for Pr.06-55 for more information.
 When the load is a shock or impact load, use a higher level model.

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General

Series	MS300
Category	DC Drives
IP Rating	IP66
NEMA Rating	NEMA 4X
Control Method	V/F, SVC
Communication Interface	RS-485
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Altitude	Up to 1000m
Vibration	1.0G
Input Voltage	Single/Three Phase 200-240V, Three Phase 380-480V
