11 Summary of Parameter SettingsMS300 (IP66 / NEMA 4X)
11-1
11 Summary of Parameter Settings
All parameters and setting values in MS300 (standard models) series are applicable for those in
MS300 (IP66 / NEMA 4X) series except the following. Refer to Chapter 11 in MS300 (standard
models) series for the rest of parameter settings.
1. Pr.00-20, setting value is 7
2. Pr.00-30, setting value is 7
3. Pr.03-39
4. Pr.03-40
5. Pr.03-41
6. Pr.03-42
7. Pr.03-43
Download the MS300 (standard models) series user manual at:

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Delta Compact Drive MS300 IP66/NEMA 4X Series and is the answer not in the manual?

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General IconGeneral
SeriesMS300
CategoryDC Drives
IP RatingIP66
NEMA RatingNEMA 4X
Control MethodV/F, SVC
Communication InterfaceRS-485
Operating Temperature-10°C to 50°C
Storage Temperature-20°C to +60°C
Humidity90% RH, non-condensing
AltitudeUp to 1000m
Vibration1.0G
Input VoltageSingle/Three Phase 200-240V, Three Phase 380-480V
