Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 5 Main Circuit TerminalsMS300 (IP66 / NEMA 4X)
5-8
Frame C
 If you install at Ta 40 °C environment, select copper wire with voltage rating of 600 V and
temperature resistance of 75 °C or 90 °C.
 If you install at Ta 40 °C above environment, select copper wire with voltage rating of 600 V and
temperature resistance of 90 °C or above.
 For UL installation compliance, use copper wires when installing. The wire gauge is based on
temperature resistance of 75 °C, in accordance with UL requirements and recommendations. Do not
reduce the wire gauge when using high-temperature resistant wires.
Models
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
DC-, DC+/+1, +2/B1, B2
Ground Terminals
Max. Wire
Gauge
Min. Wire
Gauge
Screw and
Torque (±10 %)
Max. Wire
Gauge
Min. Wire
Gauge
Screw and
Torque (±10 %)
VFD25AMS23MNSAA
10 mm
2
[8 AWG]
10 mm
2
[8 AWG]
M4
20 kg-cm
[17.4 lb-in.]
[1.96 Nm]
10 mm
2
[8 AWG]
10 mm
2
[8 AWG]
M4
20 kg-cm
[17.4 lb-in.]
[1.96 Nm]
VFD13AMS43MNSAA
6 mm
2
[10 AWG]
6 mm
2
[10 AWG]
6 mm
2
[10 AWG]
VFD13AMS43MFSAA
VFD17AMS43MNSAA
10 mm
2
[8 AWG]
10 mm
2
[8 AWG]
10 mm
2
[8 AWG]
VFD17AMS43MFSAA
Table 5-5

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General

Series	MS300
Category	DC Drives
IP Rating	IP66
NEMA Rating	NEMA 4X
Control Method	V/F, SVC
Communication Interface	RS-485
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Altitude	Up to 1000m
Vibration	1.0G
Input Voltage	Single/Three Phase 200-240V, Three Phase 380-480V
