Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 7 Optional Accessories  MS300 (IP66 / NEMA 4X)
7-6
Model
Voltage/
one-phase
(three-phase)
Current Input / Output
(Maximum)
AC Input Terminal
Fuse
[A]
Brake Fuses
(Terminal B1&B2)
[A]
Normal Duty Heavy Duty
VFD5A5MS43MNSXX
VFD5A5MS43MFSXX
7.2 A / 6.5 A 6.1 A / 5.5 A
26
HINODE
1000GH-16UL
Class T JJS-25
VFD9A0MS43MNSXX
VFD9A0MS43MFSXX
11.6 A / 10.5 A 9.9 A / 9.0 A
31.5
HINODE
1000GH-16UL
Class T JJS-35
VFD13AMS43MNSXX
VFD13AMS43MFSXX
17.3 A / 15.7 A 14.3 A / 13.0 A
34.54
HINODE
1000GH-25UL
Class T JJS-35
VFD17AMS43MNSXX
VFD17AMS43MFSXX
22.6 A / 20.5 A 18.7 A / 17.0 A
45.1
HINODE
1000GH-32UL
Class T JJS-45

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General

Series	MS300
Category	DC Drives
IP Rating	IP66
NEMA Rating	NEMA 4X
Control Method	V/F, SVC
Communication Interface	RS-485
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Altitude	Up to 1000m
Vibration	1.0G
Input Voltage	Single/Three Phase 200-240V, Three Phase 380-480V
