Chapter 7 Optional Accessories MS300 (IP66 / NEMA 4X)
7-21
EMC Filter Dimension
EMF11AM21A
EMF10AM23A
EMF6A0M43A
Screw Torque
M5 * 2 16–20 kg-cm / [13.9–17.3 lb-in.] / [1.56–1.96 Nm]
M4 * 2 14–16 kg-cm / [12.2–13.8 lb-in.] / [1.38–1.56 Nm]
Unit: mm
[inch]

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Delta Compact Drive MS300 IP66/NEMA 4X Series and is the answer not in the manual?

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General IconGeneral
SeriesMS300
CategoryDC Drives
IP RatingIP66
NEMA RatingNEMA 4X
Control MethodV/F, SVC
Communication InterfaceRS-485
Operating Temperature-10°C to 50°C
Storage Temperature-20°C to +60°C
Humidity90% RH, non-condensing
AltitudeUp to 1000m
Vibration1.0G
Input VoltageSingle/Three Phase 200-240V, Three Phase 380-480V
