Delta DVP-ES3 Series User Manual

DVP-ES3 Series Operation Manual
5-24
_5
5.3.2 DVP02DA-E2 / DVP4DA-E2 Control Registers
CR#
Attrib.
Register name
Explanation
0 O R Model name
Set up by the system, model code:
DVP02DA-E2 = H’0041; DVP04DA-E2 = H’0081
1
O
R
Firmware version
Display the current firmware version in hex.
2
O
R/W
CH1 output mode setting
Output mode: Default = H’0000.
Mode 0 (H’0000): Voltage output (±10V)
Mode 1 (H’0001): Current output (0~+20mA)
Mode 2 (H’0002): Current output (+4~+20mA)
Mode -1 (H’FFFF): All channels are unavailable
3
O
R/W
CH2 output mode setting
4 O R/W CH3 output mode setting
5 O R/W CH4 output mode setting
16
X
R/W
CH1 output signal value
Voltage output range: K-32,000~K32,000. Current output range:
K0~K32,000.
Default: K0.
CR#18~CR#19 of DVP02DA-E2 are reserved.
17
X
R/W
CH2 output signal value
18
X
R/W
CH3 output signal value
19
X
R/W
CH4 output signal value
28
O
R/W
Adjusted Offset value of CH1
Set the adjusted Offset value of CH1 ~ CH4. Default = K0
29
O
R/W
Adjusted Offset value of CH2
30
O
R/W
Adjusted Offset value of CH3
31
O
R/W
Adjusted Offset value of CH4
34
O
R/W
Adjusted Gain value of CH1
Set the adjusted Gain value of CH1 ~ CH4. Default = K16,000.
35 O R/W Adjusted Gain value of CH2
36 O R/W Adjusted Gain value of CH3
37 O R/W Adjusted Gain value of CH4
Adjusted Offset Value, Adjusted Gain Value:
Note1: When using Mode 2, the channel do NOT provide setups for adjusted Offset or Gain value.
Note2: When output mode changes, the adjusted Offset or Gain value automatically returns to defaults.
40 O R/W
Function: Set value changing
prohibited
Prohibit set value changing in CH1 ~ CH4. Default= H’0000.
41 X R/W
Function: Save all the set
values
Save all the set values. Default =H’0000.
43 X R Error status
Register for storing all error status. Refer to table of error statu
s for more
information.
100 O R/W
Function: Enable/Disable limit
detection
Upper and lower bound detection, b0~b3 corresponds to CH1~CH4 (0:
Disable/ 1: Enable). Default= H’0000.
101 X R/W Upper and lower bound status
Display the upper and lower bound status. (0: Not exceed /1: Exceeds
upper or lower bound value), b0~b3 corresponds to Ch1~Ch4 for lower
bound detection result; b8~b11 corresponds to CH1~CH4 for upper
bound detection result..
102
O
R/W
Set value of CH1 upper bound
Set value of CH1~CH4 upper bound. Default = K32000.
103
O
R/W
Set value of CH2 upper bound
104
O
R/W
Set value of CH3 upper bound
105
O
R/W
Set value of CH4 upper bound
108
O
R/W
Set value of CH1 lower bound
Set value of CH1~CH4 lower bound. Default = K-32000.
109
O
R/W
Set value of CH2 lower bound
110 O R/W Set value of CH3 lower bound
111
O
R/W
Set value of CH4 lower bound
114
O
R/W
Output update time of CH1
Set value of CH1~CH4 lower bound. Setting range: K0~K100. Default
=H’0000.
115
O
R/W
Output update time of CH2
116
O
R/W
Output update time of CH3
