Delta DVP-ES3 Series

Chapter 9 Ethernet Specification and Operation
9-59
9_
 When Instance = 1, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data
Type
Values Description
H’00 D0.0 Set
BOOL
H’00 D0.0 bit register
H’01 D0.1 Set
BOOL
H’00 D0.1 bit register
H’02-H’752FE D0.2-D29999.14 Set
BOOL
H’00 D0.2-D29999.14 bit register
H’752FF D29999.15 Set
BOOL
H’00 D29999.15 bit register
 When Instance = 2, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data
Type
Values Description
H’00 D0 Set INT H’00 D0 word register
H’01 D1 Set INT H’00 D1 word register
H’02-H’752E D2-D29998 Set INT H’00 D2-D29998 word register
H’752F D29999 Set INT H’00 D29999 word register
9.7.13 M Register (Class ID: 353 Hex)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
H’0E Get_Attribute_Single X V Read one attribute
H’10 Set_Attribute_Single X V Write one attribute
H’32 Read_Parameter X V Read Parameter
H’33 Write_Parameter X V Write Parameter
 Class
 Class ID：H’353
 Instance
 H’01：Instance Attribute, Bit Register
