Delta DVP-ES3 Series

Chapter 5 CPU and Module Devices
5-35
5_
5.3.4 DVP04PT-E2 /DVP06PT-E2 Control Registers
04PT
06PT
Attrib.
Register content
Description
0 0 O R Model name
DVP04PT-E2 model code = H’0082
DVP06PT-E2 model code = H’00C2
1
1
O
R
Firmware version
Display the current firmware version in hex.
2
2
O
R/W
CH1 Input mode setting
Input mode: Default = H’0000. Take CH1 for example:
Mode 0 (H’0000): Pt100: -180°C ~ 800°C
Mode 1 (H’0001): Ni100: -80°C ~ 170°C
Mode 2 (H’0002): Pt1000: -180°C ~ 800°C
Mode 3 (H’0003): Ni1000: -80°C ~ 170°C
Mode 4 (H’0004): 0~300Ω
Mode 5 (H’0005): 0~3000Ω
Mode 6 (H’0006): JPt100 (-180°C ~ 500°C)
Mode 7 (H’0007): Cu50 (-50°C ~ 150°C)
Mode 8 (H’0008): Cu100 (-50°C ~ 150°C)
Mode 9 (H’0009): LG-Ni1000 (-50°C ~ 180°C)
Mode -1 (H’FFFF): Channel unavailable
Note: 04PT-E2 do NOT support mode 6-9.
3
3
O
R/W
CH2 Input mode setting
4 4 O R/W CH3 Input mode setting
5 5 O R/W CH4 Input mode setting
6 O R/W CH5 Input mode setting
7 O R/W CH6 Input mode setting
7 O R/W Temperature unit setting
Select the temperature unit (Celsius °C / Fahrenheit °F).
Default = H’0 (°C)
8
8
O
R/W
CH1 average times
Average times setting of channel CH1 ~ CH6
Setting range: K1 ~ K100
Default = K10
9
9
O
R/W
CH2 average times
10
10
O
R/W
CH3 average times
11
11
O
R/W
CH4 average times
12
O
R/W
CH5 average times
13
O
R/W
CH6 average times
12 14 X R
Average temperature
measured at CH1
Average temperature measured.
Setting Temperature Unit :
● DVP04PT-E2: CR#7
● DVP06PT-E2: CR#27
13 15 X R
Average temperature
measured at CH2
14 16 X R
Average temperature
measured at CH3
15 17 X R
Average temperature
measured at CH4
18 X R
Average temperature
measured at CH5
19 X R
Average temperature
measured at CH6
20 20 X R
Present temperature
measured at CH1
Present temperature measured.
Setting Temperature Unit :
● DVP04PT-E2: CR#7
● DVP06PT-E2: CR#27
21 21 X R
Present temperature
measured at CH2
22 22 X R
Present temperature
measured at CH3
23 23 X R
Present temperature
measured at CH4
24 X R
Present temperature
measured at CH5
