Chapter 6 Writing a Program
6-15
Select the network
Select the input contact
Select the network
Select the output coil
Select the block
To select a group of devices, click a device and drag it to draw a frame around the group of devices. You can
also select the group of devices by clicking the first device, pressing Ctrl+B on the keyboard, clicking the last
device, and then pressing Ctrl+B on the keyboard. You must draw a frame around devices that are in the same
network, and the devices must be adjacent to one another. Input and output devices cannot be in the same
frame.
To select several networks, press and hold the Ctrl key on the keyboard and click the networks. You can also
select a range of networks by pressing and holding Shift on the keyboard, clicking the first network within the
range, and then clicking the last network within the range.
Right-click an object after selecting it to show the context menu.
Item Function
Undo
Undo the last action.
You can undo up to 20 previous actions.
Redo You can redo an action that has been undone.
Cut Cut a device, block, or network.
Copy Copy a device, block, or network.
