Delta E Series Software Instructions

Recipe Setting Software Instruction
19
Output
Modbus
(Delta PLC)
Name Definition
Y0
0x08FA
(M250)
Ready
After the machine is started, it will continuously output this signal.
When the servo press is off, this signal will stop.
Y1
0x08FB
(M251)
Waiting
Waiting for the trigger signal to press down. This signal will cease
during the pressing process, and will not restart until the pressing
action is completed.
Y2
0x08FC
(M252)
Alarm
When the machine has an abnormality and outputs an alarm,
this
point will continue to output.
Y3
0x08FD
(M253)
OK/NG
When the pressing action is completed, this point signal will be
output if the pressing is successful, and this point signal will not be
output if the pressing has failed.
