Delta E Series Software Instructions

Recipe Setting Software Instruction
20
3.2 External Process
3.2.1 External I/O initialization
1. Switch the control selector button to [External Control]
2. Trigger the [Safety Signal]. [X3]→ON
3. Please refer to the table below to select a recipe with binary values
Recipe number
X7
Bit 3
X6
Bit 2
X5
Bit 1
X4
Bit 0
1 OFF OFF OFF ON
2 OFF OFF ON OFF
3 OFF OFF ON ON
4 OFF ON OFF OFF
5 OFF ON OFF ON
6 OFF ON ON OFF
7 OFF ON ON ON
8 ON OFF OFF OFF
9 ON OFF OFF ON
10 ON OFF ON OFF
11 ON OFF ON ON
12 ON ON OFF OFF
13 ON ON OFF ON
14 ON ON ON OFF
15 ON ON ON ON
4. Trigger the [On] signal, and the machine will perform [Initialize] and [Start]. [X0]→Continuous ON
5. After the initialization of the machine is completed, the signal of [Ready] is output.
[Y0]→Continuously ON

Delta E Series Specifications

General

Series	E Series
Type	Inverter
Frequency	50 Hz / 60 Hz
Protection Features	Over voltage, Over current, Short circuit, Over temperature
Dimensions	Varies by model
Weight	Varies by model
Storage Temperature	-40°C ~ +70°C
