ASDA-A2 Chapter 1 Inspection and Model Explanation
1-4 Revision February, 2017
1.2.2 Model Explanation
ASDA-A2 Series Servo Drive
ASD-A2-0743-U
Model Type
Type RS-485
(CN3)
Full-closed
control
(CN5)*1
Extension
Port for
Digital
Input
(CN7)
EtherCAT CANopen DMCNET Analog
Voltage
Control
Pulse
Input
Port
PR
Mode*2
E-Cam*3
Standard
Model
L O O X X X X O O O X
U O O O X X X O O O O
Network
Model
E X O O O X X X X O O
F O O X X X O X X O X
M O O X X O X O O O O
NOTE
1. In PR mode, only A2-F supports full-closed control function.
2. PR parameters can be read and written through communication by DMCNET only.
3. E-cam function can only be used in PR mode.
Input Voltage and Phase
21: 220V 1 phase
23: 220V 3 phase
43: 400V 3
p
hase
Model Type
Series
A2
Product Name
AC SERVO Drive
Rate Output Power
01: 100W 20: 2kW
02: 200W 30: 3kW
04: 400W 45: 4.5kW
07: 750W 55: 5.5kW
10: 1kW 75: 7.5kW
15: 1.5kW 1B: 11kW
1F: 15kW
