ASDA-A2 Chapter 11 Specifications
11-10 Revision February, 2017
ECMA Series
C△10
C△13
10
20
30
Operating temperature (
o
C)
0
o
C to 40
o
C
Storage temperature (
o
C)
-10
o
C to 80
o
C
Operating humidity
20% to 90% RH (non-condensing)
Storage humidity
20% to 90% RH (non-condensing)
Vibration capacity
2.5 G
IP Rating
IP65 (use the waterproof connector
and shaft seal installation (or oil seal)
model)
Approvals
Note:
*1 The rated torque is the continuous permissible torque between 0~40˚C operating temperature
which is suitable for the following heat sink dimension.
ECMA-__04 / 06 / 08 : 250 mm x 250 mm x 6 mm
ECMA-__10 : 300 mm x 300 mm x 12 mm
ECMA-__13 : 400 mm x 400 mm x 20 mm
ECMA-__18 : 550 mm x 550 mm x 30 mm
ECMA-__22 : 650 mm x 650 mm x 35 mm
Material: Aluminum – F40, F60, F80, F100, F130, F180, F220
*2 The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to
decelerate or as the dynamic brake.
