Delta ECMA-C 0807 Series User Manual

ASDA-A2 Chapter 11 Specifications
11-42 Revision February, 2017
NOTE
1) Dimensions are in millimeters. Actual measured values are in metric units.
2) Dimensions of the servo motor may be revised without prior notice.
3) The boxes () in the model names represent shaft end/brake or the number of oil seal.
4) Please refer to Chapter 1 for the boxes (△ ) in the model names (which represents encoder type).
Model
C△0804 7
C△0807 S
C△0807 H
C△0907 S
C△0910 S
LC
80
80
80
86
86
LZ
6.6
6.6
6.6
6.6
6.6
LA
90
90
90
100
100
S
)
(14
0
011.0


)
(19
0
013.0


)
(19
0
013.0


)
(16
0
011.0


)
(16
0
011.0


LB
)
(70
0
030.0


)
(70
0
030.0


)
(70
0
030.0


)
(80
0
030.0


)
(80
0
030.0


LL
(without brake)
112.3
138.3
154.8
130.2
153.2
LL
(with brake)
152.8
178
187.8
161.3
184.3
LS
27
32
32
30
30
LR
30
35
35
35
35
LE
3
3
3
3
3
LG
8
8
8
8
8
LW
20
25
25
20
20
RH
11
15.5
15.5
13
13
WK
5
6
6
5
5
W
5
6
6
5
5
T
5
6
6
5
5
TP
M4
Depth 15
M6
Depth 20
M6
Depth 20
M5
Depth 15
M5
Depth 15
