ASDA-A2 Chapter 11 Specifications
11-46 Revision February, 2017
Motor Frame Size: 180 mm Models (Units: mm)
Model
F△1845□S
F△1855□3
F△1875□3
LC
180
180
180
LZ
13.5
13.5
13.5
LA
200
200
200
S
)
(
.
35
0
0160


)
(
.
42
0
0160


)
(
.
42
0
0160


LB
)
(.
.
3114
0
0350


)
(.
.
3114
0
0350


)
(.
.
3114
0
0350


LL (without brake)
235.3
279.7
342.0
LL (with brake)
279.3
311.7
376.1
LS
73
108.5
108.5
LR
79
113
113
LE
4
4
4
LG
20
20
20
LW
63
90
90
RH
30
37
37
WK
10
12
12
W
10
12
12
T
8
8
8
TP
M12
Depth25
M16
Depth32
M16
Depth32
NOTE
1) Dimensions are in millimeters. Actual measured values are in metric units.
2) Dimensions of the servo motor may be revised without prior notice.
3) The boxes () in the model names represent shaft end/brake or the number of oil seal.
4) Please refer to Chapter 1 for the boxes (△ ) in the model names (which represents encoder type).
