Delta Part Number: ASD-CAPW2303, ASD-CAPW2305 (for motors with brake)
Title Part No. Straight
L
mm inch
1 ASD-CAPW2303 3106A-20-18S
3000  100 118  4
2 ASD-CAPW2305 3106A-20-18S
5000  100 197  4
Delta Part Number: ASD-CAPW3203, ASD-CAPW3205 (for 4.5 kW models)
Title Part No. Straight
L
mm inch
1 ASD-CAPW3203 MS 3106-24-11S
3000  100 118  4
2 ASD-CAPW3205 MS 3106-24-11S
5000  100 197  4
L
(100 mm)
(3.15 inch)
(3.94 inch)
(80mm)
