Appendix A Accessories ASDA-A2
A-26 Revision February, 2017
7.5kW Servo Drive and 7.5kW Medium-High Inertia Servo Motor
Servo Drive ASD-A2-7523-
Medium-High Inertia Servo Motor
ECMA-F△18753
Motor Power Cable (Without Brake) -
Motor Power Cable (With Brake) -
Power Connector ASD-CAPW4000
Brake Connector ASD-CNBR1000
Incremental Type Encoder Cable ASD-CAEN100X
Absolute Type Encoder Cable ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
11kW Servo Drive and 11kW Medium-High Inertia Servo Motor
Servo Drive ASD-A2-1B23-
Medium-High Inertia Servo Motor ECMA-F1221B3
Motor Power Cable (Without Brake) -
Motor Power Cable (With Brake) -
Power Connector ASD-CAPW4000
Brake Connector ASD-CNBR1000
Incremental Type Encoder Cable ASD-CAEN100X
Absolute Type Encoder Cable ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
15kW Servo Drive and 15kW Medium-High Inertia Servo Motor
Servo Drive ASD-A2-1F23-
Medium-High Inertia Servo Motor ECMA-F1221FS
Motor Power Cable (Without Brake) -
Motor Power Cable (With Brake) -
Power Connector ASD-CAPW4000
Incremental Type Encoder Cable ASD-CAEN100X
Absolute Type Encoder Cable ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
