Control Types
Page 80 of 84 eZV-440 Application Guide
Edition 2.6
Physical Output Control Types
Universal Analog, binary, time proportioned, tri-state open, tri-state close
TRIAC Binary, time proportioned, tri-state open, tri-state close
As another example, the physical outputs of the eZFC-424R4-24 controller support specific control
types. See the screenshot below for more details. In this case, outputs 1 to 4 do not support analog
control because they are TRIAC physical outputs. If you select HydronicDuct as a Function option
in outputs 1 to 4 in enteliWEB, the analog Control Type option is absent.
