25
PLANING WARPED PIECES
If the wood to be planed is dished or warped, take light
cuts until the surface is flat. Avoid forcing such material
down against the table; excessive pressure will spring it
while passing the knives, and it will spring back and
remain curved after the cut is completed.
Fig. 70
DIRECTION OF GRAIN
Avoid feeding work into the jointer against the grain as
shown in Fig. 72. The result will be chipped and
splintered edges. Feed with the grain as shown in Fig.
73, to obtain a smooth surface.
PLANING SHORT OR THIN WORK
When planing short or thin pieces, always use push
blocks to minimize all danger to the hands. Fig. 70,
illustrates using the Delta Push Blocks properly.
Fig. 71
WRONG FEED - AGAINST THE GRAIN
Fig. 72
IN-FEED TABLE
OUT-FEED
TABLE
CUTTER
CORRECT FEED - WITH THE GRAIN
Fig. 73
IN-FEED TABLE
OUT-FEED
TABLE
CUTTER
TROUBLESHOOTING
For assistance with your machine, visit our website at www.deltamachinery.com for a list of service centers or call
the DELTA Machinery help line at 1-800-223-7278 (In Canada call 1-800-463-3582).
DO NOT PERFORM PLANING OPERA-
TIONS ON MATERIAL SHORTER THAN
10 INCHES (254 mm), NARROWER
THAN 3/4 INCH (19 mm), WIDER THAN
6 INCHES (152.4 mm) OR LESS THAN
1/2 INCH (12.7 mm) THICK
MINIMUM AND MAXIMUM PLANING DIMENSIONS
1/2" (12.7 mm)
MINIMUM
3/4" (19mm) MINIMUM
6" (152.4 mm)
MAXIMUM
10" (254 mm) MINIMUM
