Delta JT360 User Manual

9
JOINTER PARTS
Fig. 4
1. Motor and Switch
2. Jointer
3. Motor Pulley
4. V-Belt
5. Two Top End Braces for Stand (11-3/4")
6. Two Top Side Braces for Stand (15-3/4")
7. Two Lower Side Braces for Stand (20-1/2")
8. Two Lower End Braces for Stand (16-1/2")
9. Four Legs for Stand
10. Four Feet for Stand Legs
11. Cutterhead Guard
12. Fence Locking Handle
13. Fence Tilting Handle
14. Dust Chute
15. Dust Chute Cover
16. 6mm Allen Wrench
17. 4mm Allen Wrench
18. 3mm Allen Wrench
19. 2.5mm Allen Wrench
20. 12x14mm Open End Wrench
21. 8x10mm Open End Wrench
22. Rear Cutterhead Guard
23. Fence
24. Motor Pulley and Belt Guard
Fig. 4A
25. Dust Collector Adapter
26. Push Blocks
27. Infeed Table Adjustment Rod, Handle, and Nut
Fig. 4B
28. Special Studs (3)
29. 5/16-18x1¼" Carriage Bolts (4)
30. 5/16-18x3/4" Carriage Bolts (36)
31. M6x1x10mm Cheese Head Screws (4)
32. Wing Screws (2)
33. 5/16-18Hex Nuts (40)
34. 5/16 Flat Washers (36)
35. M10.2 Lockwashers for Special Studs (3)
36. M8.4 Flat Washer
37. M6.1 Lockwashers (4)
