Delta RPI-H5

3.2 Function Introduction
Inverter’s exterior objects are shown on the Figure 3-3, and the detailed description is
in sections 3.2.1 and 3.2.2.
LCD / LED display and
buttons
DC Switch
DC connectors
AC connector
Communication
connections
Label
Dry connector & Digital input
Figure 3-3 : Inverter exterior objects
RPI-H3
RPI-H5
LCD / LED display and
buttons
DC Switch
DC connectors
AC connector
Communication
connections
Label
H3_110: DC Switch
(H3_010: No DC switch)
14
Product Overview
