6.2.4 Reactive Power / Voltage Characteristic Q(U)(CEI 0-21)
Once user enables this method, user can set Q vs. Grid voltage operation curve as below.
U
Q/Sn
(%)
U1s
U2s
U1i
U2i
Qmin(48.4%)
Qmax(48.4%)
U
Q/Sn
(%)
U1s
U2s
U1i
U2i
TypeA
TypeB
Figure 6-3 : Q(U) characteristic
32
Active/Reactive Power Control and LVRT (Optional)
