Delta RPI-H5 User Manual

Model
Housing
Cooling
IP rating
External communication
Weight
Dimensions
Aluminum Extrude
2 RS-485 connection
21.5 kg15 kg
482 × 470 × 167 mm367 × 420 × 157 mm
Natural cooling
IP65 (Electronics)
AC OUTPUT (Grid side)
Safety
Grid interface
IEC 62109-1
IEC 62109-2
CE compliance
VDE 0126 A1
VDE AR-N 4105
UTE 15-712-1
EN 50438
C10/C11
G83-2
AS 4777(#3)
VDE AR-N 4105
RD1699
CEI-021
Emission IEC 61000-6-4, IEC 61000-6-3
Harmonics EN 61000-3-12
Variations and flicker EN 61000-3-11
Immunity EN 61000-6-2
Immunity
ESD
RS
EFT
Surge
CS
PFMF
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
REGULATIONS & DIRECTIVES
RPI-H3 RPI-H5
#1: (a) 2.49kW max. for Australia (AU / NZ PL 2K49) (H3)
(b) 2.99kW max. for Australia (AU / NZ PL 2K99) (H3)
(c) 3kW max. for Australia (AU / NZ) (H3)
#2: Disable reactive power control
#3: Not support AS4777.2:2015 Single-phase inverters used in three-phase combinations
Table 11-1 : Specifications
Internal fuse, 20 A/250 V*1 Internal fuse, 20 A/250 V*2
Output connection
Fuse
IP 67 single-phase
MECHANISM
55
Technical Data

Delta RPI-H5 Specifications

General

Brand	Delta
Model	RPI-H5
Category	Inverter
Language	English
